Applied Biosystems 7300 User Manual

Chapter 4 Performing the Regions of Interest (ROI) Calibration
Creating a Plate Document for the ROI Calibration
Applied Biosystems 7300/7500/7500 Fast Real-Time PCR System Installation and Maintenance Guide 43
Notes
4
5. In the ROI Inspector dialog box, right-click the
black area of the window, then select Display
Properties.
6. In the Image Viewer Control Properties dialog box:
a. Select Show Saturation.
b. In the Sat Threshold field, enter 4000.
c. Click .
7. In the ROI Inspector dialog box, set the lamp
control:
a. Click .
b. Select Idle from the Lamp Control
drop-down list (sets the lamp to lower
voltage for ROI calibration).
Continue with “Performing the ROI Calibration” on
page 44.
Select
b
c
a
b
a
