ASE2000 V2 Communication Test Set User Manual 101

19. ASE2000 Kit Components

19.1. ASE dual channel BCOM-USB device with two RS-232

cables, USB cable, and BCOM-USB to ASE 2-Channel

Modem power cable.

19.2. ASE Bell-202/CCITT V.23 Dual-Channel Modem

Default Chapter3
