ASE2000 V2 Communication Test Set User Manual 82
12. Project Saving
Beginning with version 2.21, users can now save task properties into a project le (.A2K). Some
properties are not saved, as altering would aect the overall application behavior, hence user
will need to make such task property changes explicitly after opening the project or starting the
application.
To save a project, simply click “File” in the menu bar, then “Save As” and give the appropriate
name and le location.
When a user saves a project, it will capture the following information from saved projects.
• Master / RTU Simulation mode
• Exchange/Task mode
• Task mode properties
Note: only static property settings that do not aect application behavior will be saved.
User can open the project by double clicking on the .a2k in Windows or by going to “File” in the
menu bar and clicking “Open.
