ASE2000 V2 Communication Test Set User Manual 49
Messages sent by the RTU means:
• In Master Simulation mode, messages received from the RTU
• In RTU Simulation mode, messages sent by the ASE2000
• In Line Monitor mode, messages detected on the channel designated as “To RTU”
Individual counters and their meanings are:
Total The left cell is total Messages Sent by the Master”. The right cell is total “Messages
Sent by the RTU”
OK Of the total messages transmitted in either direction, the number processed with no
communication error
No Resp Of the total “Messages Sent by the Master”, those to which the RTU should have
responded but did not
Line Error Of the total messages transmitted in either direction, the number detected with word
parity or framing errors
Sec Error Of the total messages transmitted in either direction, the number detected with
protocol security errors such as CRC, BCH, or Checksum
Totals can be reset by right-clicking in the Status Bar and selecting Reset Statistics
