ARS Flexibowl 200 - Technical Specifications

26 CHAPTER 4 - Description of the machine
FlexiBowl® - Models 200 - 350 - 500 - 650 - 800
4.4 Technical specifications
Power supply specifications
Power supply
110 - 220Vac +/-5%
Frequency
50/60 Hz
230 VAC current
6 A
Air supply specifications
Air pressure
6 bar
Air characteristics
• Dried
• Filtered
General specifications
Flexibowl® 200
Flexibowl® 350
Flexibowl® 500
Flexibowl® 650
Flexibowl® 800
Backlit area dimensions
90 cm
2
177 cm
2
475 cm
2
900 cm
2
1183 cm
2
Infrared backlight
20,000 - 30,000 hours; 850 nm LED
Ethernet ports
1
Digital I/O
13 inputs, 3 outputs
Weight
Flexibowl® 200
Flexibowl® 350
Flexibowl® 500
Flexibowl® 650
Flexibowl® 800
Net weight
18 Kg
25 Kg
42 Kg
54 Kg
71 Kg
Component specifications
Flexibowl® 200
Flexibowl® 350
Flexibowl® 500
Flexibowl® 650
Flexibowl® 800
Maximum single component
dimension
10 mm
20 mm
50 mm
110 mm
250 mm
Maximum single component
weight
20 g
40 g
100 g
170 g
250 g
Maximum loading capacity
1 Kg
3 kg
7 kg
7 kg
7 kg
