7.3.6 Replacing the motor
REPLACING THE MOTOR
Operator qualification
Mechanical maintenance technician
PPE required
Tool to be used
Allen key
CAUTION!
Disconnect the power supply before taking the cover off.
Proceed as follows to replace the motor on models 200 and 350:
Step
Action
1
Unplug the power cable from the control panel.
2
Take the cover off the Flexibowl®.
3
Take the Rotary Disc off.
4
Loosen the shrink disk that attaches the flange to the motor.
5
Remove the flange.
6
Remove the shrink disk.
7
Remove the 4 screws that fix the motor to the Flexibowl®.
8
Replace the motor with one with the same characteristics.
Note: the flange must be installed at 1.5 mm from the sliding Rotary Disc.
