6.3.3.2 Programming and handling via digital I/O
CAUTION!
Disconnect the input connectors, if connected.
The program to modify the movement parameters of the Flexibowl® is on the USB flash drive, sent with the system.
Proceed as follows for programming using the digital I/O:
Step
Action
1
Use the Flexibowl® Parameters utility supplied by ARS S.r.l. to set the movement parameters.
2
From utility, enable the Enable Digital I/O function.
3
Turn the Flexibowl® off and then on again.
4
Wait for the Ready/Fault LED to turn green, after about 2 seconds the Flexibowl® will be in I/O mode.
The operating principle is as follows:
• Apply 24Vdc to the input relating to the command to be carried out for about 50ms. The Busy output will be ON for the
entire duration of the movement.
• The Busy output is available between Pin 1 and 5 of the Output connector.
IMPORTANT!
Do not send a new movement command until the Busy signal is OFF. Otherwise the command will be ignored.
INPUTS TABLE:
PIN
Command
1
Move
2
Move - Flip
3
Move - Blow - Flip
4
Move - Blow
5
Shake
6
Light on
7
Light off
8
Flip
9
Reset Alarm
10
Quick Emptying option
11
Emptying Door open (read only)
12
Emptying Door closed (read only)
Note: if any movement command is sent and the “Quick emptying option” door is low, the Flexibowl® will go in Fault
