CHAPTER 5 - Transport and Installation 41
Instructions for use and warnings
5.3.3 Installation site
For installation, prepare an area suitable for the dimensions of the machine and lifting vehicles, paying attention to any obstacles
(other machines, walls or similar) along the path of the handling vehicles.
5.3.4 Machine position
Place the Flexibowl®
on a stable surface.
Note: if the Flexibowl® is installed on a machine platform (sensitive to vibrations), put some insulating and
vibration damping material between the platform and the Flexibowl®.
Fix the Flexibowl® through the holes.
Note: the Flexibowl®
has 4 holes for M6 screws on its base so that it can be fixed to a surface.
Connect as necessary (see the “Connections” section).
CAUTION!
Leave a space of approximately 100mm for the power supply connectors of the Flexibowl®
CAUTION!
Make sure the machine support surface is flat and horizontal and can withstand its weight.
