Artos CS-326 - Feed Roller Pressure; Wire Length Calibration

27
SETTING IN STEPS GAP IN IN. GAP IN MM
2400 0.39 9.91
2000 0.33 8.26
1600 0.26 6.60
1200 0.20 4.95
800 0.13 3.30
400 0.07 1.65
0 0.00 0.00
Table 1 OUTFEED GAP
FeedRollerPressure(1-100%)
This sets the amount of gripping pressure used to feed and strip the wire by the feed wheels or
belts.
Note: The feed rollers or belts must be opened and closed to affect a change in this setting.
WireLengthCalibration. (50.00 3.94in. / 1270 100.0mm)
This setting compensates for the different measuring characteristics of the various types of wire.
Wire calibration by manually entering the calibration value in the Wire
Properties screen.
1. Open the Wire properties screen.
2. Set the Wire Length Calibration value to 50.
3. Click the green check to exit.
4. Run the length of wire you need.
5. Measure the wire.
6. Open the Wire properties screen
7. Use the following formula to determine the calibration number.
In Inches
(50*measured length)/programmed length = calibration value
In metric
(1270*measured length)/programmed length = calibration value
8. Enter the number you calculated above for the calibration value.
Wire calibration using the calibration routine in the Wire Properties
screen.
1. Open the wire properties screen shown above.
2. Click the calibration button.
