ASCOM D81 User Manual

TD 92644EN
User Manual
Ascom d81 DECT Handset
7 Menu Operation
84
18 June 2018 / Ver. K
Subscribe Handset in DECT System Manually
To subscribe an DECT system manually, the “Park:” (Portable Access Right Key) and “Ac:”
(Authentication code) related to the system are needed. Contact the system administrator
for more information.
NOTE: The PARK code may not be needed if there is no alien DECT system within the
coverage area.
1 Enter the menu by pressing "Menu".
2 Select in the menu.
3 Select "System".
4 Select "Subscribe".
5 The handset’s IPDI is displayed. The IPDI is a unique code that has been assigned to
the handset. Press "Next".
6 Enter System name (optional). If no system name is entered, the default name is
used. That is System A, System B etc. depending on which system name that is free.
Note: The System name might not be displayed depending on the handset’s Display
Management Layout setting. See the handset’s Configuration Manual.
7Press "Next".
8 Enter PARK code (max. 31 digits). The PARK code may not be needed if there is no
alien DECT system within the coverage area.
9 Enter AC code. The AC code length must be between 4 - 8 digits.
10 Press "Next".
11 An information text "Protection on?" is displayed. Select "Yes" if the new system is to
be protected.
NOTE: It is not possible to unsubscribe a protected system via the System menu. The
unsubscribtion must be made via the Admin menu or the DECT system.
12 Press "OK". A searching mode starts.
Unsubscribe System
1 Enter the menu by pressing "Menu".
2 Select in the menu.
3 Select "System".
4 Select "Unsubscribe".
5 Select the system to unsubscribe.
6 Press "Yes to unsubscribe the system.
Rename System
It is possible to change the name of the system in the handset.
1 Enter the menu by pressing the “Menu” soft key.
2 Select in the menu.
3 Select "System".

ASCOM D81 Specifications

General

Brand	ASCOM
Model	D81
Category	Handsets
Language	English
