TD 92644EN
User Manual
Ascom d81 DECT Handset
14 Maintenance
96
18 June 2018 / Ver. K
Figure 14. Update Completed while in Charger
14 Maintenance
14.1 Maintenance of Batteries
14.1.1 Battery Warnings
During a call, only the corresponding battery warning signal will notify the user. The warning
signal cannot be silenced during a call. When not in call, the warning signal can be silenced
by pressing or .
14.1.2 Charge the Battery
Place the handset in the desktop charger or in the rack charger. The battery is being
charged when the LED on the handset is steady orange. When the battery is fully charged
the LED is green.
An animated battery icon is also shown in the display indicating charging by starting
with its current charge and ending with the full charge. A filled battery icon indicates a
fully charged battery.
NOTE: Only use the prescribed chargers for charging.
The "Low battery" icon is displayed when the battery has 10% or less
remaining capacity left. In addition; a warning signal sounds every minute,
the LED flashing orange, and the dialog window "Battery low. Charge
now." appears.
The "Empty battery" icon is flashing when the battery has 5% or less
remaining capacity left. In addition; a warning signal sounds every
second, the LED flashing red, and the dialog window "Battery empty.
Shutting down." appears.
13:03
2013-03-06
OK
Handset is Updated
System A
