4.
Communication settings of the RX-5000i-Plus/RX-5000i/RX-7000i/RX-9000i
1. Touch "SET UP" on the
home screen.
2. Touch "SERIAL.”
3. Enter the following serial
settings.
From the Instrument to a Computer
Apply sample/purified water and touch "START.”
Every time a measurement is taken, a new row of data appears in the Tera Term window.
Data format
YYMMDD Date (year, month, day)
HHMM Time (hour, minute)
R Measurement value (each 'R' representing a digit)
UUUU Scale name (when measured in a user or special scale)
XXXXXXX Measurement value in the user/special scale above (up to 7 digits including the
decimal separator)
TT.TT Temperature
C/RL/F Line break or carriage return
＿ Enter a space (one character)
※
Below are the setting details:
BAUDRATE: 9600 BPS
DATA LENGH: 7 BIT
PARITY: ODD
STOP BIT: 1 BIT
Touch those keys to change the
values.
