Diagnostic M0022
Bluetooth M0244
The following states can be checked via diagnostic:
SignificationMenu IDParameters
Information for actuator identification within the plant
(e.g. KKS designation - Power Plant Classification sys-
tem)
(Can be changed for user level Specialist (4) and higher)
M0223Device tag
Bluetooth address (BD_ADDR) of controlsM0222Bluetooth address
Bluetooth address (BD_ADDR) of the Bluetooth partnerM0576Bluetooth add.partner
13.3. Diagnostic Interface
Required user level: Specialist (4) or higher.
Diagnostic M0022
Interface M0239
The following states can be checked via the menu:
SignificationMenu IDParameters
Shows configuration, coding and state of the input sig-
nals.
M0245States DIN
Shows configuration and current value at analogue input
1.
M0246States AIN 1
Shows configuration and current value at analogue input
2.
M0583States AIN 2
Shows configuration, coding and state of the output
signals.
M0247States DOUT
Shows configuration and current value at analogue
output 1.
M0248States AOUT 1
Shows configuration and current value at analogue
output 2.
M0584States AOUT 2
Status of the interface
M0730Interface status
Diagnostics of digital inputs
For the digital inputs (DIN), both coding and signal states are indicated at the input
by means of symbols.
Table 13: Symbol explanation
Input stateSignal (command)CodeSymbol
Low level = 0 V or input openNot activeHigh active
High level = Default: +24 V DCActiveHigh active
High level = Default: +24 V DCNot activeLow active
Low level = 0 V or input openActiveLow active
Figure 51: Example of DIN 4 and DIN 5
●
Configuration:
- DIN 4: Operation command OPEN
- DIN 5: Operation command for EMERGENCY behaviour
105
Actuator controls
ACV 01.2/ACVExC 01.2 Diagnostics
