Customer settings M0041
Intermediate positions M0143
Operation behaviour M0257
Operation behaviour 1 M0258
Default value: Off
Setting values:
Off
No intermediate stop, actuator continues the operation.
Stop in OPEN
●
Actuator stops at pivot point during operation in direction OPEN.
●
Another operation command must be issued to resume operation.
●
This function is not active in operation mode Remote SETPOINT.
Stop in CLOSED
●
Actuator stops at pivot point during operation in direction CLOSE.
●
Another operation command must be issued to resume operation.
●
This function is not active in operation mode Remote SETPOINT.
Stop in OPEN & CL.
●
Actuator stops automatically upon reaching the pivot point.
●
Another operation command must be issued to resume operation.
●
This function is not active in operation mode Remote SETPOINT.
Off time in OPEN
Actuator stops at pivot point during operation in direction OPEN. If an operation
command in direction OPEN is present at the end of the pause time, the actuator
resumes operation into direction OPEN. If an operation command in direction CLOSE
is present during the pause time, the pause is aborted and operation into direction
CLOSE resumed.
Off time in CLOSED
When reaching the pivot point, the actuator stops during operation in direction CLOSE.
If an operation command in direction CLOSE is present at the end of the pause time,
the actuator resumes operation into direction CLOSE. If an operation command in
direction OPEN is present during the pause time, the pause is interrupted and
operation into direction OPEN resumed.
Off time in OPEN & CL.
Actuator stops automatically upon reaching the pivot point. If an operation command
in direction OPEN or CLOSE is present at the end of the pause time, the actuator
resumes operation depending on the operation command.
Information
The actuator stops for each activated intermediate position for which operation be-
haviour Stop in OPEN, Stop in CLOSED or Stop in OPEN & CL. is assigned.
8.3.3. Off times for intermediate positions (pivot points): set
An off time can be defined for each pivot point.
If a pivot point is reached with the operation behaviour Off time in OPEN , Off time
in CLOSED or Off time in OPEN & CL., the actuator controls generate a signal during
off time:
Required user level: Specialist (4) or higher.
Customer settings M041
Intermediate positions M0143
Off times M0268
Off time 1 M0285
Default values: 00:01,0 min:s (1 second)
Setting ranges: 00:00.2 ... 30:00,0 min : s (0.2 seconds – 30 minutes)
8.4. Two-wire control
Conditions
Operation mode Remote (Selector switch = position Remote control).
Characteristics
With the function <Two-wire control>, the actuator can be operated to end position
OPEN or CLOSED via a digital input.
Information
In this function, the actuator only reacts to commands via the input OPEN / CLOSE.
Other inputs to which the operation commands OPEN, STOP, CLOSE were assigned,
do not have any function.
51
Actuator controls
ACV 01.2/ACVExC 01.2 Application functions
