AUMA ACVExC 01.2 Series User Manual

13.5. Diagnostic Position transmitter RWG
Menu is only visible if the actuator is equipped with electronic position transmitter
(RWG).
Required user level: Observer (1) or higher.
Diagnostic M0022
Position transm. RWG M0996
The following states can be checked via diagnostic:
SignificationMenu IDParameters
Low limit setting of RWG signal for wire break monitoringM1010Low limit RWG
Raw value end position OPENM0997Raw val. pos. OPEN
Raw value end position CLOSEDM0998Raw val. pos. CLOSED
RWG raw value /mAM1000RWG raw value /mA
13.6. Diagnostic Position transmitter MWG
Menu is only visible if the actuator is equipped with magnetic limit and torque
transmitter (MWG).
Required user level: Observer (1) or higher.
Diagnostic M0022
Position transm. MWG M1006
The following states can be checked via diagnostic:
SignificationMenu IDParameters
Minimum stroke of MWGM1007Minimum stroke
Maximum stroke of MWGM1012Maximum stroke
Absolute value in end position OPENM1011Abs. end pos. OPEN
Absolute value in end position CLOSEDM1008Abs. end pos. CLOSED
Absolute value of MWGM1009Absolute value
13.7. Diagnostic positioner
Required user level: Specialist (4) or higher.
Diagnostic M0022
Positioner M0613
Menu M0613 is only visible if function Positioner M0158 is activated.
The following states can be checked via diagnostic:
BedeutungMenu IDParameters
Setting the adaptive behaviour of the positionerM0626Adaptive behaviour
Setpoint positionM0622Setpoint position
Actual positionM0623Actual position
Outer dead band OPENM0625Outer dead b. OPEN
Outer dead band CLOSEM1002Outer dead b. CLOSE
Inner dead band OPENM1003Inner dead b. OPEN
Inner dead band CLOSEM1004Inner dead b. CLOSE
13.8. Diagnostic On time monitoring
Menu is only visible if on time monitoring (parameter Duty type monitoring M0573)
is activated.
Required user level: Observer (1) or higher.
Diagnostic M0022
Operation mode M0593
107
Actuator controls
ACV 01.2/ACVExC 01.2 Diagnostics
