The following states can be checked via diagnostics:
SignificationMenu IDParameters
On timeM0594On time
Number of motor starts/hM0595No. mot. starts/h
13.9. Diagnostic Process controller
Required user level: Specialist (4) or higher.
Diagnostic M0022
Process controller M0883
Menu M0883 is only visible if function Process controller M0741 is activated.
The following states can be checked via diagnostic:
SignificationMenu IDParameters
Process setpoint of PID controllerM0884Process setpoint
Actual process value of PID controllerM0885Actual process value
Calculated setpoint position for subordinate controllerM0886Op. com. PID contr.
13.10. Diagnostic FO cable
Menu is only visible if on time monitoring (parameter Duty type monitoring M0573)
is activated.
Required user level: Observer (1) or higher.
Diagnostic M0022
FO cables M0638
The following states can be checked via diagnostic:
SignificationMenu IDParameters
FO cable receive level channel 1M0639FOC level channel 1
The signal assignment for DIN 4 (digital input 4) is incor-
rect.
M0640DIN 4 configuration
RS-485 format error of FOC sub-assemblyM0762FOC RS-485 error
FO cable baud rateM0641FO cable baud rate
FO cables FPGA versionM0711FOC FPGA version
13.11. Simulation (inspection and test function)
The service personnel or the commissioning engineer can use this simulation function
to simulate the operation and failure behaviour of the actuator or the actuator controls
to check the interface to the DCS and the correct behaviour of the DCS.
13.11.1. Actuator signals
By simulating the actuator signals, the signal behaviour of the actuator controls to
the DCS can be tested, for example, without having to connect the actuator.
Required user level: Specialist (4) or higher.
Diagnostic M0022
Simulation M0023
Actuator signals M0024
Simulation values:
End position OPEN
End position OPEN reached.
End position CLOSED
End position CLOSED reached.
Torque fault OPEN
Torque in direction OPEN reached.
Torque fault CLOSE
Torque in direction CLOSE reached.
Thermal fault
Motor protection tripped (thermal fault)
108
Actuator controls
Diagnostics ACV 01.2/ACVExC 01.2
