Setting ranges/values:
Max. value at 100.0 % = 1 – 1000
Scaling = 0.001 – 1000
Unit = mA; °C; bar; m³/h; m³/min; m; cm; mm; °
7.5.7. Process factor units
Process factors (e.g. process setpoint, actual process value...) are shown in percent
of travel in the actuator controls display (default setting). By activating the parameter
Process factor, you may select other physical units apart from percent.The
change-over affects all screens indicating a process value.
Activate process factor units
Required user level: Specialist (4) or higher.
Display... M0009
Units M1205
Process factor M1211
Proc. var. activation M1212
Default value: Function not active
Setting values:
Function not active
<Process factor units> deactivated. Position indications in the display are shown in
percent.
Function active
<Process factor units> activated. Position indications in the display are not shown
in percent but in the unit set for the values in parameter group Process factor.
Set max. value, scaling and unit
Required user level: Specialist (4) or higher.
Display... M0009
Units M1205
Process factor M1211
Max. value at 100.0 % M1213
Scaling M1214
Unit M1215
Default values:
Max. value at 100.0 % = 1000
Scaling = 1 (multiplier for unit)
Unit = mA
Setting ranges/values:
Max. value at 100.0 % = 1 – 1000
Scaling = 0.001 – 1000
Unit = mA; °C; bar; m³/h; m³/min; m; cm; mm; °
7.5.8. Analogue working value units (AIN)
Activate working value units (AIN)
Required user level: Specialist (4) or higher.
Display... M0009
Units M1205
Working values (AIN) M1216
Work. val. activ. (AIN) M1217
Default value: Function not active
Setting values:
Function not active
<Working value units (AIN)> function deactivated.
Function active
<Working value units (AIN)> function activated.
43
Actuator controls
ACV 01.2/ACVExC 01.2 Basic settings for commissioning
