Actuator serial number
Table 1:
Description of serial number (with example 0516MD12345)
MD123451605
Positions 1+2: Assembly in week = week 0505
Positions 3+4:Year of manufacture = 201616
Internal number for unambiguous product identificationMD12345
Terminal plan
Position 9 after TPA: Position transmitter version
0 = Without position transmitter
A, B, J, K, L, N, R,T = Potentiometer
C, D, E, G, H, M, P, S, U = Electronic position transmitter
I, Q = MWG (magnetic limit and torque transmitter)
Control
Table 2:
Control examples (indications on actuator controls name plate)
DescriptionInput signal
Control voltage 24 V DC for OPEN - CLOSE control via digital inputs (OPEN,
STOP, CLOSE)
24 V DC
Control voltage 48 V DC OPEN - CLOSE control via digital inputs (OPEN,
STOP, CLOSE)
48 V DC
Control voltage 60 V DC OPEN - CLOSE control via digital inputs (OPEN,
STOP, CLOSE)
60 V DC
Control voltage 115 V AC for OPEN - CLOSE control via digital inputs (OPEN,
STOP, CLOSE)
115 V AC
Input current for setpoint control via analogue input0/4 20 mA
Data Matrix code
When registered as authorised user, you may use the AUMA Support App to scan
the Data Matrix code and directly access the order-related product documents without
having to enter order number or serial number.
Figure 3: Link to the AUMA App:
For further software/apps refer to chapter <Service software> or to the Internet:
www.auma.com.
2.2. Short description
Actuator controls
ACV 01.2/ACVExC 01.2 actuator controls are used to operate AUMA actuators and
are supplied ready for use.The actuator controls may be mounted directly to the
actuator or separately on a wall bracket.
The functions of ACV 01.2/ACVExC 01.2 actuator controls include standard valve
control in OPEN-CLOSE duty, positioning, process control, logging of operating data
right through to diagnostic functions.
Local controls/
AUMA CDT
Operation, setting, and display can be performed directly at the actuator controls.
When set to local control, it is possible to
operate the actuator via the local controls (push buttons and display) and perform
settings (contents of these instructions).
read in or out data or modify and save settings via AUMA CDT software (ac-
cessory), using a computer (laptop or PC).The connection between computer
and actuator controls is wireless via Bluetooth interface (not included in these
instructions).
Intrusive - Non-Intrusive
Intrusive version (control unit: electromechanical):
Limit and torque setting is performed via switches in the actuator.
11
