10.6.3. Travel difference dx
Required user level: Specialist (4) or higher.
Customer settings M0041
Motion detector M0676
Travel diff. dx M0678
Travel diff. dx (MWG) M0679
Default values:
Travel diff. dx (for potentiometer/EWG/RWG within actuator) = 1.0 %
Travel diff. dx (MWG) (for MWG within actuator) = 3 (increments)
Setting ranges:
Travel diff. dx = 1.0 ... 10.0 %
Travel diff. dx (MWG) = 2 ... 20 (increments)
10.6.4. Delay time
Delay time of the signal: Handwheel oper.
Required user level: Specialist (4) or higher.
Customer settings M0041
Motion detector M0676
Delay time M0764
Default value: 6.000 s (seconds)
Setting range: 0.001 ... 65.535 s
10.7. Vibration/oscillation monitoring
Requirements
Electronic control unit within the actuator (non-intrusive version).
Characteristics
The actuator controls monitor vibration by means of an acceleration sensor at the
MWG.
If certain limits are exceeded or fallen short of, the actuator controls either send a
warning or a fault signal.
Parameters for setting limit values
Required user level: Specialist (4).
Device configuration M0053
Monitoring functions M0645
Vibration alarm level M1657
Vibration alarm time M1658
Vibration alarm level M1657
Limit value (at sensor) for triggering the acceleration alarm (warning).
Default value:1.000 g
Setting range: 0.5000 ... 4.000 g
Vibration alarm time M1658
Interval during which the vibration limit must be exceeded until the vibration alarm
is triggered (fault signal).
Default value:0.1 s (seconds)
Setting range: 0.1 ... 10.0 s
Information
The acceleration values of oscillation/vibration measurement can either be displayed
or sent to an analogue output. Refer to <Oscillation/vibration indication>.
95
Actuator controls
ACV 01.2/ACVExC 01.2 Monitoring functions
