7.5.4. Torque unit
The torque can be indicated in different units.
Display... M0009
Torque unit M0051
Default value: Nm
Setting values:
Nm
Indication in Nm
ft-lb
Indication in foot-pound
%
Indication in percent
7.5.5. Temperature unit
The temperature unit can either be displayed in Celsius [C°] or Fahrenheit [°F].
Display... M0009
Temperature unit M0052
Default value: °C
Setting range: °C or °F
7.5.6. Position units
The valve position (e.g. actual position, setpoint position) or other positions (e.g.
pivot points) are indicated in percent of the travel on the actuator controls display
(default setting).. By activating the parameter Position, you may select other physical
units instead of percent to represent the positions. Furthermore, both scaling and
maximum value may be adapted. The change-over affects all screens indicating a
position.This includes status pages such as S0001 S0003, but also the
representation of characteristics (e.g. position-time) as well as histograms.
Activate position unit
Required user level: Specialist (4) or higher.
Display... M0009
Units M1205
Position M1206
Position activation M1207
Default value: Function not active
Setting values:
Function not active
<Units of position> function deactivated. Position indications in the display (e.g. the
valve position S0001) are indicated in percent.
Function active
<Units of position> function activated. Position indications in the display are not
shown in percent but in the unit set for the values in parameter group Position.
Set max. value, scaling and unit
Required user level: Specialist (4) or higher.
Display... M0009
Units M1205
Position M1206
Max. value at 100.0 % M1208
Scaling M1209
Unit M1210
Default values:
Max. value at 100.0 % = 1000
Scaling = 1 (Multiplikator für Einheit)
Unit = mA
42
Actuator controls
Basic settings for commissioning ACV 01.2/ACVExC 01.2
