Table 18:
Faults and Failure
RemedyDescription/causeIndication on display
Press push button Details to display a list of indi-
vidual indications.
For a description of the individual signals, refer to
<Individual signals> table/ Configuration error (col-
lective signal 11).
Collective signal 11:
Configuration error has occurred.
Configuration error
Press push button Details to display a list of indi-
vidual indications.
For a description of the individual signals, refer to
<Individual signals> table/ Config. error REMOTE
(collective signal 22).
Collective signal 22:
Configuration error has occurred.
Config. error REMOTE
AUMA service
Press push button Details to display a list of indi-
vidual indications.
For a description of the individual signals, refer to
<Individual signals> table/ Internal error (collective
signal 14).
Collective signal 14:
Internal error has occurred.
Internal error
Perform one of the following measures:
●
Issue operation command in direction OPEN.
●
Set selector switch to position Local control
(LOCAL) and reset fault indication via push
button RESET.
Torque fault in direction CLOSE
Torque fault CLOSE
Perform one of the following measures:
●
Issue operation command in direction CLOSE.
●
Set selector switch to position Local control
(LOCAL) and reset fault indication via push
button RESET.
Torque fault in direction OPEN
Torque fault OPEN
Test/connect phases.
●
When connecting to a 3-ph AC system and with
internal 24 V DC supply of the electronics:
Phase 2 is missing.
●
When connecting to a 3-phase network: One of
the phases L1, L2 or L3 is missing.
Phase fault
●
Check mains voltage.
●
Check parameter Tripping time M0172, extend
time frame if required.
Due to insufficient mains quality, the controls cannot
detect the phase sequence (sequence of phase
conductors L1, L2 and L3) within the pre-set time
frame provided for monitoring.
Mains quality
●
Cool down, wait.
●
If the fault indication display persists after cool-
ing down:
-
Set selector switch to position Local con-
trol (LOCAL) and reset fault indication via
push button RESET.
●
Check fuses.
Motor protection tripped
Thermal fault
Check movement at actuator.No actuator reaction to operation commands within
the set reaction time.
Fault no reaction
Check device configuration:
Parameter Low limit Uspan M0832 must be less
than parameter Volt.level diff. potent. M0833.
Potentiometer is outside the permissible range.
Poti Out of Range
Check wiring.Loss of signal analogue input 1
Wrn input AIN 1
Check wiring.Loss of signal analogue input 2
Wrn input AIN 2
Check operation command control.
For 3-phase AC current mains, activate phase
monitoring (parameter Adapt rotary dir. M0171).
Check device configuration setting (parameter
Closing rotation M0176).
To delete the fault indication: Disconnect actuator
controls from the mains and perform reboot.
Contrary to the configured direction of rotation and
the active operation command, the motor turns into
the wrong direction.
Incorrect rotary direct.
Check Deviation MA/SA [%] parameter.
Synchronous link function: Actual position values
of master actuator and slave actuator are not syn-
chronous (excessive deviation).
Syn. link deviation
Check Deviation MA/SA [%] parameter.
Synchronous link function: Slave actuator is not
ready.
Syn. link NotReady
Check wiring.Synchronous link function: Signal loss of actual po-
sition value from master actuator or slave actuator.
Syn. link wire break SA
124
Actuator controls
Corrective action ACV 01.2/ACVExC 01.2
