③ Main Section
④ Function Buttons
4.2.4.1 Top Toolbar Buttons
Table 4-2 Top Toolbar Buttons on Service Menu
Returns to the previous screen.
Returns to the MaxiTPMS Job Menu.
Includes Data Logging and Report
functions.
⚫ Data Logging: Records the
communication data and ECU
information of the test vehicle. See
Data Logging on page 146 for details.
⚫ Report: Displays the TPMS test
report page. See TPMS TEST
REPORT on page 138 for details.
is displayed at the upper corner of the
screen when the VCI is not successfully
connected to the tablet. After the MaxiVCI
V200 is successfully connected to the
tablet, the icon is changed to (with
a check mark).
4.2.4.2 Navigation Tab
The navigation tab at the top of the Main Section screen contains the
following items:
1. Check Tab – triggers sensors and displays sensor data.
