6.12. Route Pattern for Calls within the CPE
This form defines the Route pattern for the local SIP trunk, based on the route-pattern selected by
the AAR table in Section 6.13 (e.g., calls to Avaya SIP telephone extensions or Messaging).
Step 1 - Enter the change route-pattern 3 command and enter the following:
In the Grp No column enter 3 for SIP trunk 3 (local trunk).
In the FRL column enter 0 (zero).
In the Numbering Format column, across from line 1, enter lev0-pvt.
6.13. Automatic Alternate Routing (AAR) Dialing
AAR is used for outbound calls within the CPE.
Step 1 - Enter the change aar analysis 0 command and enter the following:
Dialed String - In the reference configuration all SIP telephones used extensions in the
range 14xxx, therefore enter 14.
Min & Max – Enter 5
Route Pattern – Enter 3
Call Type – Enter lev0
Step 2 - Repeat Step 1, and create an entry for Messaging access extension (not shown).
change aar analysis 0 Page 1 of 2
AAR DIGIT ANALYSIS TABLE
Location: all Percent Full: 1
Dialed Total Route Call Node ANI
String Min Max Pattern Type Num Reqd
14 5 5 3 lev0 n
change route-pattern 3 Page 1 of 3
Pattern Number: 3 Pattern Name: ToSM Enterprise
SCCAN? n Secure SIP? n Used for SIP stations? y
Primary SM: SM Secondary SM:
Grp FRL NPA Pfx Hop Toll No. Inserted DCS/ IXC
No Mrk Lmt List Del Digits QSIG
Dgts Intw
1: 3 0 n user
2: n user
3: n user
BCC VALUE TSC CA-TSC ITC BCIE Service/Feature PARM Sub Numbering LAR
0 1 2 M 4 W Request Dgts Format
1: y y y y y n n rest lev0-pvt none
change private-numbering 0 Page 1 of 2
NUMBERING - PRIVATE FORMAT
Ext Ext Trk Private Total
Len Code Grp(s) Prefix Len
5 10 3 5 Total Administered: 6
5 11 3 5 Maximum Entries: 540
5 12 3 5
5 14 3 5
5 20 3 5
