5.3. Configure Adaptations
Session Manager can be configured to use Adaptation Modules to convert SIP headers sent from
Verizon to Communication Manger.
Calls from Verizon - Modification of SIP messages sent to Communication Manager
extensions/VDNs.
The Verizon called number digit string in the Request URI is replaced with the associated
Communication Manager extensions defined for Agent skill queue VDNs/telephones.
5.3.1 Adaptation for Avaya Aura® Communication Manager Extensions
The Adaptation administered in this section is used for modification of SIP messages to
Communication Manager extensions from Verizon.
Step 1 - In the left pane under Routing, click on Adaptations. In the Adaptations page, click on
New (not shown).
Step 2 - In the Adaptation Details page, enter:
1. A descriptive Name, (e.g., CM-TG2-VzIPCC).
2. Select DigitConversionAdapter from the Module Name drop down.
3. Select Name-Value Parameter from the Module Parameter Type drop down:
Name: fromto Value: true
o This adapts the From and To headers along with the Request-Line and PAI
headers.
Name: osrcd Value: avayalab.com
o This enables the source domain to be overwritten with “avayalab.com”. For
example, for inbound PSTN calls from Verizon to Communication
Manager, the PAI header will contain “avayalab.com”.
Note – Depending on the Communication Manager configuration, it may not be necessary for
Session Manager to adapt the domain in this fashion.
Step 3 - Scroll down to the Digit Conversion for Outgoing Calls from SM section (the inbound
toll-free numbers from Verizon that need to be replaced with their associated
Communication Manager extensions before being sent to Communication Manager).
