DDT; Reviewed:

SPOC 10/18/2017

Solution & Interoperability Test Lab Application Notes

25 of 95

CM71SM71-VzIPCC

5.4.3 Avaya Aura® Communication Manager SIP Entity – Local Trunk

To configure the Communication Manager Local trunk SIP Entity, repeat the steps in Section 5.4.2

with the following changes:

 Name – Enter a descriptive name (e.g., CM-TG3).

 Adaptations – Leave this field blank.

5.4.4 Avaya Session Border Controller for Enterprise SIP Entity

Repeat the steps in Section 5.4.2 with the following changes:

 Name – Enter a descriptive name (e.g., SBC1).

 FQDN or IP Address – Enter the IP address of the A1 (private) interface of the

Avaya SBCE (e.g., 10.64.91.50, see Section 7.5.1).

 Type – Select SIP Trunk.

 Adaptations – Select Adaptation SBC1-Adaptation for Verizon (Section 5.3.2).

5.4.5 Avaya Aura® Messaging SIP Entity

Repeat the steps in Section 5.4.2 with the following changes:

 Name – Enter a descriptive name (e.g., Aura Messaging).

 FQDN or IP Address – Enter the IP address of Messaging (e.g., 10.64.91.54).

 Type – Select Messaging.

 Adaptations – Leave this field blank.

5.5. Entity Links

In this section, Entity Links are administered for the following connections:

 Session Manager to Communication Manager Public trunk (Section 5.5.1).

 Session Manager to Communication Manager Local trunk (Section 5.5.2).

 Session Manager to Avaya SBCE (Section 5.5.3).

 Session Manager to Messaging (Section 5.5.4).

Note – Once the Entity Links have been committed, the link information will also appear on the

associated SIP Entity pages configured in Section 5.4.

Note – See the information in Section 5.4 regarding the transport protocols and ports used in the

reference configuration.

5.5.1 Entity Link to Avaya Aura® Communication Manager – Public Trunk

Step 1 - In the left pane under Routing, click on Entity Links, then click on New (not shown).

Step 2 - Continuing in the Entity Links page, provision the following:

 Name – Enter a descriptive name for this link to Communication Manager (e.g., SM to

CM TG2).

 SIP Entity 1 – Select the SIP Entity administered in Section 5.4.1 for Session Manager

(e.g., SessionManager).

 Protocol – Select TLS (see Section 6.8.1).
