AVL F-FEM-DDC User Manual

11
What you should know
F-FEM-DDC — User’s Guide
1 What you should know
1.1 Safety Instructions
This documentation contains important warnings and safety instructions to be
observed by the user. Smooth operation only is ensured, if the necessary
prerequisites and safety measures are kept.
1.2 Warranty Seal
For safety reasons the product is provided with a special seal which may only be
broken by AVL personnel. Any unauthorized damage to the seal is considered
an unauthorized change to the product which will cease AVL's warranty obliga-
tion.
1.3 Intended Application
The product is only intended for the area of application described in the docu-
mentation. We do not give any warranty and do not accept any liability for appli-
cations outside the described utilization or in the event of noncompliance with
the necessary conditions and safety instructions. The supported protection of the
product could be affected.
1.4 Product specific information
The F-FEM (Fast–Front End Module) represents the current generation of
Front End Modules (FEMs). Data communication happens via an IEEE1394
interface to PUMA test bed workstation. Thus, within a PUMA system real time
data communication is ensured.
Compatibility The F-FEM-DDC can be used with PUMA Open automation system.
Function of the
F-FEM-DDC
The F-FEM-DDC has outputs for voltages and currents, as well as In- and
Outputs for digital signals. The digital Inputs are equipped with a counter func-
tion.
Front view for F-FEM-DDC IP20:
Drawing of the front view for F-FEM-DDC IP20:
Fig. 1

AVL F-FEM-DDC Specifications

General

Brand	AVL
Model	F-FEM-DDC
Category	Measuring Instruments
Language	English
