79
Technical Data
F-FEM-DDC Users Guide
6 Technical Data
6.1 Electrical, mechanical and environmental Specifications
6.2 CE-Conformity
2004/108/EC Directive on Electromagnetic Compatibility met with the following
standards complied:
EN 61326-1:06 Electrical Equipment for Measurement, Control and Labora-
tory use
Area of application:
Class A equipment with reference to EMC:
2006/95/EC Low Voltage Directive met with the following standards complied:
EN 61010-1:10 Safety Requirements for Electrical Equipment, for Measure-
ment, Control and Laboratory Use.
Description Data
Case dimension: Width 19", Depth, Height 1 HU, 485 × 210 × 43 mm (W × D × H)
Depth without connectors
Supply Voltage: 24 V DC ± 20 %
Reverse battery protection provided
Power consumption: 8 W typ.
12 W max. without external loads on Digital I/O
150 W max depending on the loads on X41 - X54
Ambient temperature: 0 °C to 60 °C
Storing temperature: –20 °C to 85 °C
Relative humidity: 20 % to 80 %, non-condensing
Number of channels: 8 analog outputs
16 digital inputs (can feed 8 counter channels)
16 digital outputs (8 relay, 8 transistor)
Interfaces: 3 x IEEE1394
Cable lengths IEEE1394: Max. 20 m
for longer distances: Repeater required
Weight: 1.9 kg
Protection class: IP20
Tab. 33
NOTICE
Equipment suitable for use in establishments other than domestic and those
directly connected to a low voltage power supply network which supplies build-
ings used for domestic purposes.
