AVL F-FEM-DDC User Manual

Operation
50
F-FEM-DDC — User’s Guide
4.8.2 Analog Outputs X1... X8
Fig. 26
Information
The D-SUB jacks are equipped with a quick lock™ option for an easy click &
mount and a one hand remove mechanism.
Pin Signal at X1 ... Signal at X4
1 AOGND1-4 (for U) AOGND1-4 (for U)
2 Uout1+ Uout4+
3 Iout1+ Iout4+
4 AOGND1-4 (for I) AOGND1-4 (for I)
5 AOGND_1-4 (opt.) AOGND_1-4 (opt.)
6Nc Nc
7 Shield (opt.) Shield (opt.)
8Nc Nc
9 GND_24V GND_24V
Case Shield Shield
Tab. 16
Pin Signal at X5 ... Signal at X8
1 AOGND5-8 (for U) AOGND5-8 (for U)
2 Uout5+ Uout8+
3 Iout5+ Iout8+
4 AOGND5-8 (for I) AOGND5-8 (for I)
5 AOGND_5-8 (opt.) AOGND_5-8 (opt.)
6Nc Nc
7 Shield (opt.) Shield (opt.)
8Nc Nc
9 GND_24V GND_24V
Case Shield Shield
Tab. 17
Information
The maximum cross section of a wire soldered to a D-SUB connector pin is
limited to 0.5 mm² (equivalent to AWG 20 or more).
