Installation
F-FEM-DDC Users Guide
3 Installation
3.1 Scope of supply
Normally, the F-FEM-DDC is delivered as part of the test bed. It is integrated into
the cabinet and ready to use. If you order it separately, it is delivered in a box
and includes the following attachments:
4 fixing screws for the fixation in a 19" rack
an envelope with calibration and test protocol
8 pieces of 9 pin D-SUB plugs with Quicklock hoods for the analog outputs
connectors
If you need additional accessories, please see chapter Options on page 57.
3.2 Mechanical Installation
Space requirement: 19" 1HU, installation possibility into a 19" cabinet in the test
bed cell.
Fig. 4
440
485
2
1
0
2
1
0
(
o
r
2
7
1
)
465
8
4
3
3
2
5
.
5
AVL F-FEM
*
)
1
