AVL F-FEM-DDC User Manual

33
Operation
F-FEM-DDC — User’s Guide
4.1.2 Specification
4.1.2.1 Voltage Output
4.1.2.2 Current Output
*) For module Rev. ≤ 04 (see type plate) for positive current the maximum burden
is 300 Ω.
Quantity Min. Typ. Max. Unit Remark
Output Range ± 10.0 ± 10.5 V
Resolution (1 LSB) 320 μV 16 bit
Integral Nonlinearity ± 320 μV ± 1 LSB
Differential Nonlinearity ± 320 μV ± 1 LSB
Total Accuracy, including
Gain and Offset Drift Error
± 0.5 ± 1.0 mV at 25 °C ± 5 °C
± 1.1 ± 2.2 mV from 0 °C to 60 °C
Output Current ± 10 mA permanently short circuit-proof
Load (burden) 1000 W Max.100 nF
Slew Rate 0.28 0.9 V/μs Min. at 1 nF, 1000 Ω load
Output Noise 320 μV
RMS
10 Hz to 2 MHz
Tab. 6
Quantity Min. Typ. Max. Unit Remark
Output Range ± 20 ± 21 mA
Resolution (1 LSB) 1,6 μA 15 bit
Integral Nonlinearity ± 1,6 μA ± 1 LSB
Differential Nonlinearity ± 1,6 μA ± 1 LSB
Total Accuracy, including
Gain and Offset Drift Error
± 1.2 ± 2.5 μA at 25 °C ± 5 °C
± 3.3 ± 9.5 μA from 0 °C to 60 °C
Voltage at Load ± 11.0 V Iout = 20 mA
Load (burden) 0 500
300
Ω For positive current *)
For negative current
Slew Rate 0.3 1.0 mA/μs Min. at 1 nF, 300 Ω
Output Noise 1.3 μA
RMS
10 Hz to 10 kHz
Tab. 7
