MergePoint SP5x00 Manager Configuration

Figure 1.1: MergePoint SP5x00 Manager Configuration

Number Description Number Description

1 Remote User Web Interface 6 RJ-45 Ethernet Ports

2 LAN 7 Power

3 Target Device 8 Connection to the Serial Port

Table 1.1: Descriptions for MergePoint 00 Manager Configuration
