sysctl –n marvell.xxx
NOTE: The xxx value is the switch port number. The output is the current speed of the switch port. The current
speed may differ from the speed you set if you chose auto mode or negotiable mode for the speed value.
Private Subnets on the MergePoint SP5x24/SP5x40 Manager
Service processors connecting to the private subnets on a MergePoint SP5x24/SP5x40 manager
can be isolated on a management network that is separate from the production and public
networks. To enable communications between the SPs and the MergePoint SP5x24/SP5x40
manager, an Admin user must configure at least one private subnet. The Admin user then
assigns each private subnet the following:
• A name
• An address within the private subnet’s address range to be used by the SP when
communicating with the MergePoint SP manager
Any number of private subnets may be configured. Multiple private subnets may be needed if
IP addresses for SPs are not in the same range.
NOTE: If changing or deleting a private subnet, reassign all affected devices to another private subnet to avoid
making them unavailable.
NOTE: If you are using DHCP and plan to assign a 192.168.0.x address to the MergePoint SP manager, see
Setting up a private subnet and DHCP service in the 192.168.0.x range on page 198 to avoid IPaddress conflicts.
To add a private subnet:
1. Click Network - Private subnet.
2. Click Add.
3. Enter a name in the Private subnet name field.
4. In the Appliance side IP address field, enter an IP address for the MergePoint
SP5x24/SP5x40 manager within the private subnet’s network address range.
5. In the Subnet Mask field, enter a netmask for the private subnet.
6. Click Apply.
To edit a private subnet:
1. Click Network - Private subnet.
2. Click the name link of the private subnet you want to edit.
3. Modify the fields as needed.
4. Click Apply.
24 MergePoint® SP Manager Installer/User Guide
