Appendix B: Technical Specifications

Network Connection

Number 2

Type Ethernet, 10BaseT, 100BaseT, GigE

Connector RJ-45

Serial Port

Number 1

Type RS-232 serial

Connector DB9 male

Mechanical

H x W x D 4.3 x 42.7 x 35.6 cm (1.7 x 16.8 x 14 in), 1 U form factor

Weight 5.9 kg (13 lb)

Power

AC Input Voltage 100 to 240 VAC

Rated Input Current 4A maximum

Rated Input Frequency 50 to 60 Hz

Rated Output Power 260 W maximum

Rated Output Voltages +3.3 V (15 A), +5 V (25 A), +12V (18A), -12 V (1A)

BTU Rate 1400 Bus/hour (for rated output power of 260 W)

Environmental

Temperature 0° to 35° Celsius (32° to 95° Fahrenheit) operating

Humidity 10 to 90% noncondensing operating

Table B.1: MergePoint SP5x00 Manager Technical Specifications

194 MergePoint® SP Manager Installer/User Guide
