Configuring Power for the MergePoint SP manager
The MergePoint SP manager is supplied with single or dual AC or DC power supplies.
To configure AC power:
1. Make sure that the power switch on the MergePoint SP manager is turned off.
2. Plug the power cable into the MergePoint SP manager and into a power source.
3. Turn on the MergePoint SP manager.
To configure DC power:
DC power is connected to DC-powered MergePoint SP managers by way of three wires: Return
(RTN), Ground (GND) and -48VDC.
WARNING: It is critical that the power source supports the DC power requirements of your appliance. Make sure that
your power source is the correct type and that your DC power cables are in good condition before proceeding. Failure
to do so could result in damage to the equipment or in personal injury.
The following diagram shows the connector configuration for connecting DC power. You may
use either a flat-blade or Phillips screwdriver for this procedure.
