4. Check the VLAN Enable field if you need to use VLAN on BMC, and specify the
following VLAN parameters:
a. In the VLAN ID field, type the VLAN ID.
b. In the VLAN Priority field, type the VLAN priority.
5. Click Apply.
NOTE: For the MergePoint SP5x00 manager, it is strongly recommended that the VLAN ID on the BMC and the
MergePoint SP5x00 manager are the same; otherwise, the BMC cannot communicate with the MergePoint SP
manager in the VLAN mode.
To set basic provisioning parameters in the MergePoint SP5x24/SP5x40 manager:
1. Click SP - Provisioning.
2. In the Subnet drop-down menu, select a subnet.
3. Enter the username and gateway address in the fields provided.
4. In both the Password and Confirm Password field, enter the password.
5. Select VLAN Enable to use VLAN on the BMC, and specify the following parameters:
a. In the VLAN ID field, type the VLAN ID.
b. In the VLAN Priority field, type the VLAN priority.
6. Click Apply.
To set dynamic provisioning parameters:
1. Click SP - Provisioning.
2. In the Dynamic Provisioning area, enter the Start and End IP addresses of a range of
optional BMC IP addresses.
3. Click Apply.
To set static provisioning parameters:
1. Click SP - Provisioning.
2. In the Static Provisioning area, click Add and specify the requested PXE parameters.
3. Click Apply.
NOTE: To modify the static IP address, click the name link and follow the on-screen instructions. To delete a static
IP address, select the name link and click Delete.
28 MergePoint® SP Manager Installer/User Guide
