Aztech 4-Port Wireless G Router User Manual

User Manual
Page 12 of 129
Planning Your Network
Before moving ahead to setup your network, it is a good idea to draw out a network
diagram to help identify the devices and plan out how to connect these devices. The
illustration below is an example of a network diagram.
Sample network diagram
Sample network diagramSample network diagram
Sample network diagram
To create a network diagram:
 For wireless devices, identify the wireless devices you want to include in the
network
 For wired devices, identify which router port you want to use for each device.

Aztech 4-Port Wireless G Router Specifications

General

Brand	Aztech
Model	4-Port Wireless G Router
Category	Network Router
Language	English
