Device Design
Front Panel
The LEDs on the front panel gives you an idea about the power and connection status.
Label Action Description
A POWER Off No power is supplied to the device
Steady light Connected to an AC power supply
B ETHERNET Off No Ethernet connection
Steady light Connected to an Ethernet port
Blinking light Transmitting/Receiving data
C WIRELESS Off Access point is disabled
Steady light Access point is enabled
