User Manual
Page 93
of 129
Protocol The selections are TCP, UDP, ICMP, Specify, and none. If you choose Specify, you need
to enter the protocol number in the box next to the Protocol field. This field cannot
be configured alone, additional fields like IP, Source MAC, and/or Ingress Interface
should be configured. This field is also required if the source port or destination port
has been entered.
Source Port The source protocol port. You cannot configure this field without entering the
protocol first.
Destination Port The destination protocol port or port range. You cannot configure this field without
entering the protocol first.
Source MAC The MAC address of the traffic source.
Local Routing
MAC
This field is enabled only when Locally Generated is selected in the Ingress Interface
field. The mark for DNS traffic generated by different applications are described
below:
Dynamic DNS: 0xE1
Dynamic Proxy: 0xE2
Web Server: 0xE3
MSNTP: 0xE4
DHCP Server: 0xE5
IP tables Utility: 0xE6
PPP Deamon: 0xE7
IP Route: 0xE8
ATM Library: 0xE9
NET Tools: 0xEA
RIP: 0xEB
RIP v2: 0xEC
UPNP: 0xEE
Busybox Utility: 0xEF
Configuration Manager: 0xF0
DropBear Utility: 0xF1
Voice: 0
Currently routing algorithms make decision based on destination address, i.e. only
Destination IP address and subnet mask is supported. The Policy Routing page enables
you to route packets on the basis of various fields in the packet.
