Badger Meter Dynasonics TFX-5000 User Manual

Communication
Submenus
Options/Descriptions
ETHERNET/IP
(Shows only with
card installed for
AUTODETECT or
CARD TYPE is set
to ETHERNET/IP.)
WEBSERVER
Note: WEBSERVER is READ ONLY.
*DISABLED
ENABLED
DHCP
*DISABLED
ENABLED
IP ADDRESS
Numeric entry ###.###.###.###. Enter a value from 1…255 for the first value and 0…255 for the
remaining values. Option not available if DHCP is enabled.
IP ADDRESS
Numeric entry ###.###.###.###. Enter a value from 1…255 for the first value and 0…255 for the
remaining values. Option not available if DHCP is enabled.
SUBNET MASK
Numeric entry ###.###.###.###. Enter each value from 0…255. Option not available if DHCP is
enabled.
GATEWAY
Numeric entry ###.###.###.###. Enter a value from 1…255 for the first value and 0…255 for the
remaining values. Option not available if DHCP is enabled.
DNS PRIMARY
###.###.###.### Enter a value from 1…255 for the first value and 0…255 for the remaining values. It
is not recommended to use static IP address in the range of 169.254.0.0 to 169.254.255.255 because
clients may not be able to locate the DNS server.
DNS SECONDARY
###.###.###.### Enter a value from 1…255 for the first value and 0…255 for the remaining values. It
is not recommended to use static IP address in the range of 169.254.0.0 to 169.254.255.255 because
clients may not be able to locate the DNS server.
PORT
Use SoloCUE if you need to change the TCP or UDP port from the default setting:
*AUTO NEGOTIATION 10 Mbit HALF DUPLEX 10 Mbit FULL DUPLEX
100 MbIt HALF DUPLEX 100 Mbit FULL DUPLEX
ACCESS
WRITE/READ allows full access
RESET/READ allows you to read any, but only write to Flow Total Reset (cannot set up meter)
*READ ONLY allows read only
Parameter Descriptions by Menu
Page 38 October 2019TTM-UM-02222-EN-04
