4. ClickShare installation
4.8 Audio connection
About audio
The ClickShare Button captures the audio o utput of the user ’s laptop and sends it to the Base U nit together with the video signal.
The B ase Unit will then mix the audio signals from all Buttons that are sharing their content. T he mixed audio will be outp ut at line
levels from the m ini jack so cket (3.5mm) (green connector on the back of the Base unit) o r via the DisplayPort connector depending
on the selection in the Web interface..
It is up to the us er to decide whether or not to send the audio signal together with the video signal. The user can decide this by
using the same tools as he would to control the laptop’s speakers or a headphone: the audio c ontrols of the ope rating system (eg for
Windows: Control Panel > Sounds and audio dev ices) or the physical buttons on the keyboard of their laptop (mute/unmute, lower
volume, higher volum e).
There will be synchronization between the audio and video signal.
Audio via Dis playPort
When y our dis play is connected via DisplayPort and it supports audio than a separate audio connection is not necessary. The audio
signal can b e sent together with the video signal to the display. Set in the w eb interface the aud io setting to digital.
How to connect separate audio
1. Connect an audio cable with m ini jack socket (3.5mm) into the audio out of the Base unit.
Image 4-9
2. Connect the other side to the meeting room’s sound system.
Sound is not sent out
In some Windows env ironments sound is n ot sent ou t. This can be so lved as follow:
1. Right click on the sound icon in the system tray and select Playback devices.TheSou nd window opens.
2. Select Speakers ClickShare, select Set default and click Apply.
4.9 LAN connection
About LAN connection
The B ase Unit can be c onnected to a local network or directly to a laptop. For normal oper ation, a LAN connection is not nec essary.
The LAN connection can be used:
•toconfigur e your ClickShare un it
• to update the software
• for maintenance purposes
R5900004 CLICKSHARE 23/12/2014
