2. ClickShare Specifications
Antenna type : Dipole
Gain : Maximum 2dBi peak gain in 2.4GHz and 5Ghz band
Ventilation grids
Ventilation grids are foreseen on the top and both sides of the B ase Unit.
Image 2-5
Ventilation grids IN and OUT
The Base unit sucks air via the top ventilation grid and push hot air out on both sides.
Make sure not to cover the ventilation grids during operation o
f the Base Unit. Always keep a free area of
minimum 50 mm in front of all ventilation grids.
Bottom layout of the Base Unit
The se rial number label with the applicable cert
ification logos is s tuck a t the bottom of the Base Unit.
The serial numbe r label contains:
• the Barco logo
• the Barco part number
• the serial num ber
• the revision num ber
• the production date ( month/year)
• markings for applicable standards (CE, CCC, UL, ...)
• markings for was te r egulation
• “Made in ...”
2.5 About the Button
Buttom
A Button toggles the sharing of the individual PC or MAC screen on the meeting screen.
Button layout
A Button consists of three ma in com ponents.
R5900004 CLICKSHARE 23/12/2014
