8. Light processor assembly
8.6 Preparing the new light processor assembly
Only for a light pro cessor assembly in a fl ig ht c ase.
Necessary tools
Flat screwdriver 8 x 150 mm or 10 mm nut d river
How to remove from the fl ight case
1. Open all flight case locks and open the flight case.
2. Releasethetwocaptivescrewsatthebaseofthelightprocessor(1and2).Usea6mmflat screw driver or a 10 mm nut driver.
1
2
Image 8-8
Light processor assembly fixations
3. Take the light processor assembly by its hand
les (1 and 2) an d slide it forward until the positioning pins are free (A) . Than lift it
up to remo ve it from the flight case (B ).
