10. Integrator rod
10.5 Adjusting the integrator rod
Necessary tools
• Wrench 7 mm
• Torque wrench 7 mm
How to adjust
1. Loosen th e lock nut on the light pipe.
1
2
3
Image 10-11
Integrator rod adjustment
2. start up the projector but do not activate the lamp y et.
3. By us ing the Com mun icator software, s et up the projector to display a white internal pattern w ith minimum lam p power. Do not
activate the lamp yet !
a) Switch on the projector. D o not activate the lamp yet.
b) Log on to the Com municator as “Service technician” and select: Installation > Lamp > Light output, and adjust
lamp dimming slider to 0.
c) Select : Control > Test patterns > Full white
Caution: Maximum fiv e (5) s econds are allowed of minimum light output on an non-adjusted I ntegration R od. Otherwise, the
sealing between the DMD’s and the prism will be damaged.
4. Activate the lamp and z oom the projector lens in or out until the projected image is focused.
Note: Tes t pattern m ust be displayed sharp.
5. Remove the Fold Mirror cover and the Light Sensor M odule as a whole from the Light Pipe as illustrated. Rem ove both indicated
To rx screw (reference 1).
1
Image 10-12
Fold mirror, access adjustmen
ts
R5905043 DP2K-12C/11CX 19/02/2018 177
