16. Switched mode power supply
16.1 Diagnostic LEDs on the SMPS
Diagnostic LEDs
Not that the projector input cover must be r emov ed to see the LE Ds.
+12V Indicates that the supply voltage of +12 volt is present for the electronics.
+ V TE C Indicates that the voltage to drive the Peltier elem ents ( TEC), w hich are mo unted on the Light Pr ocessor u nit, is present
+24V Indicates that the supply v oltage +24 volt is present.
