21. Maintenance procedures
21.2 Removing the front dust filter
The front filter of the p rojector can be removed from the lamp side.
The filter can b e cleaned.
Remove the dust filter
1. Remove the input cover of the projector, "Removal of the input cover", page 79.
2. Release the captive screw of the front cover.
Pull the left side of the front cover 5 centimeters forwards. There is n o need to remove the c over com pletely.
Image 21-1
Dust filter access
3. Pull the small handle a little backwards and then to the front of the p rojector until the filter frame is released.
4. Slide the filter to the left.
R5905043 DP2K-12C/11CX 19/02/2018
333
