11. Lenses and Lens holder

Image 11-36

Proceed with reinstalling the Lens Holder. See procedure "Install the lens holder", page 189

The Lens Holder has to be ad justed after installation. See p rocedure "Scheimpﬂug adjustment", page 192.

R5905043 DP2K-12C/11CX 19/02/2018 203
