Barco DP2K-12C - Page 292

17. Lamp power supply
Image 17-6
Lamp out connection
5. Release the four captive screws which fasten the LPS modu le to the projector chassis. Use for that a flat screwdriver (6 x 10
mm).
Image 17-7
LPS module fixa tion
6. Hold fast the LPS module by its handles pull the LPS module out of its com partment.
Image 17-8
Remove LPS m odule
7. Remove the ADDRES S cable and save it to reuse on the new unit.
288
R5905043 DP2K-12C/11CX 19/02/2018
