42-101-01175_01178 Revision D Page | 19
b) The new window shows the updating process for the HUIM and the PCM (Figure 2.15).
Figure 2.15 HUIM and PCM Update Process Screen
Note:
 Always start updating process with HUIM. If HUIM is already updated in the unit,
the button will be disabled.
 If not ready to update the software, press “close” and a pop-up screen will
appear. Choose “later” to leave and cancel the updating process.
c) Touch the “Start HUIM Update” panel. The update will take about a minute (Figure 2.16).
Figure 2.16 HUIM Update Progress Screen
Information Panel:
Shows current Wi-Fi
connection.
Action Update Panel.
Updating progress for
HUIM and PCM.
