Baumuller b maXX 1000 - Page 161

Parameter list
Betriebsanleitung b maXX
®
1000
Document no. 5.07004.03
161
of 208
A
P1200 12th step speed frequency 0.00 to 600.00 Hz 0.00 Hz 100:1 121
P1201 13th step speed frequency 0.00 to 600.00 Hz 0.00 Hz 100:1 122
P1202 14th step speed frequency 0.00 to 600.00 Hz 0.00 Hz 100:1 122
P1203 15th step speed frequency 0.00 to 600.00 Hz 0.00 Hz 100:1 122
P1204 Display RFG input after PID control 0.00 to 600.00 Hz 0.00 Hz 100:1 122
P1210 Over-voltage stall prevention 330.0 to 410.0 V
DC
or
660.0 to 820.0 V
DC
390.0 V or 780.0 V 10:1 123
P1211 Over-current stall prevention level during acceleration 0 to 250 % 170 % 1:1 124
P1212 Over-current stall prevention level during operation 0 to 250 % 170 % 1:1 125
P1213 Over-torque detection mode 0 to 4 0 1:1 126
P1214 Over-torque detection mode level 10 to 200 % 150 1:1 126
P1215 Over-torque detection mode time 0.1 to 60.0 s 0.1 s 10:1 126
P1216 Electronic thermal overload relay selection 0 to 2 2 1:1 127
P1217 Electronic thermal characteristic 30 to 600 s 60 s 1:1 128
P1240 PWM carrier frequency selections 1 to 15 kHz 8 kHz 1:1 128
P1359 PID set point selection 0 to 5 0 1:1 130
P1360 Input terminal for PID feedback 0 to 3 0 1:1 130
P1361 Proportional gain (P) 0.0 to 10.0 1.0 10:1 131
P1362 Integral time (I) 0.00 to 100.00 s 1.00 s 100:1 s 131
P1363 Derivative control (D) 0.00 to 1.00 s 0.00 s 100:1 131
P1364 Upper bound for integral control 0 to 100 % 100 % 1:1 132
P1365 Primary delay filter time 0.0 to 2.5 s 0.0 s 10:1 132
P1366 Output frequency limit 0 to 110 % 100 % 1:1 132
P1368 Treatment of PID feedback signal error 0 to 2 0 1:1 133
P1369 Gain over the PID detection value 0.0 to 10.0 1.0 10:1 133
P1370 Skip frequency 1 upper bound 0.00 to 600.00 Hz 0.00 100:1 133
P1371 Skip frequency 1 lower bound 0.00 to 600.00 Hz 0.00 100:1 133
P1372 Skip frequency 2 upper bound 0.00 to 600.00 Hz 0.00 100:1 134
P1373 Skip frequency 2 lower bound 0.00 to 600.00 Hz 0.00 100:1 134
P1374 Skip frequency 3 upper bound 0.00 to 600.00 Hz 0.00 100:1 134
P1375 Skip frequency 4 lower bound 0.00 to 600.00 Hz 0.00 100:1 134
P1380 Source of PID set point 0.00 to 600.00 Hz 0.00 100:1 Hz 135
P1381 PID offset level 1.0 to 50.0 % 10.0 % 10:1 135
P1382 Detection time of PID offset level 0.1 to 300.0 s 5.0 s 10:1 135
P1383 Sleep/wake up detection time 0.0 to 6550.0 s 0.0 s 10:1 135
P1384 PID sleep frequency 0.00 to 600.00 Hz 0.00 100:1 Hz 136
P1385 PID wake up frequency 0.00 to 600.00 Hz 0.00 100:1 Hz 137
P1386 Minimum PID output frequency selection 0 to 1 0 1:1 137
P2030 Password protect input 0 to 9999 0 1:1 137
P2031 Password protect set 0 to 9999 0 1:1 138
P2060 Start-up display selection 0 to 4 0 1:1 139
P2061 Content of multi function display 0 to 14 0 1:1 139
P2062 Display the current set value 0.0 to 99.9 0 1:1 141
Parameter Range Standard value Internal
standard-
ization
Page
