Arena Service Manual
Data Item Data Range Increment Units
27 Dialysate Flow Rate
[300, 1000] (range can be
reduced based on calibration
set minimum [300, 500] and
set maximum [600, 1000])
100
mL/
minute
28 Standard Sodium
[130, 160] (range can be
reduced based on calibration
set minimum [130, 138] and
set maximum [148, 160])
1 mEq/L
29 Adjusted Sodium
[130, 160] (range can be
reduced based on calibration
set minimum [130, 138] and
set maximum [148, 160])
1 mEq/L
30 Sodium Profile
[130, 160] (range can be
reduced based on calibration
set minimum [130, 138] and
set maximum [148, 160])
1 mEq/L
31 UF Profile
[0.0, 4.0] (range can be
reduced based on calibration
set minimum [0.0, 0.99] and
set maximum [1.0, 4.0])
0.1 L/h
32 UF Only Segments [0,1] 1 N/A
33 Bicarb Profile
[28, 42] (If Concentrate Type
is not Acetate, range can be
reduced based on calibration
set minimum [28, 38] and set
maximum [35, 42])
1 mEq/L
34 Adjusted Bicarb
[28, 42] (If Concentrate Type
is not Acetate, range can be
reduced based on calibration
set minimum [28, 38] and set
maximum [35, 42])
1 mEq/L
35 Dialysate Temperature [35.0, 39.0] 0.1 ° C
36 Heparin Bolus Amount
[0.30, 5.00] (range can be
reduced based on calibration
set maximum [1, 5])
0.01 mL
37 Heparin Pump Rate [0.0, 5.5] 0.1 mL/hr
38 Heparin Pump Off Time
[0, 120] before end of
therapy,
0 = disabled
1 Minute
39 Prescribed Time
[0, 720] (range can be
reduced based on calibration
set minimum [0, 90] and set
maximum [600, 1200])
1 Minute
40 Hemavision Limit
{BV, HCT, None, Machine
Setting}, where BV=0,
HCT=1, etc., (Instrument
setting indicates type of limit
currently on machine)
N/A N/A
41 HCT Limit [5, 60] 1 HCT
42 Blood Volume Limit [-80, 0] 1 %
15-6 157-1278-922 Rev A
January 2004
